一、 HT - TS-I 全自動臺式數控光纖激光切管機或HT-TS-II全自動臺式數控光纖激光坡口切管機工作原理及應用區域的介紹：
一、HT-TV-I全自動上料伺服隨動數控光纖激光切管機(HT-TV-II全自動上料伺服隨動數控光纖坡口激光切管機)工作原理及應用區域的介紹：
工作原理：
管材固定與定位：將待切割的管材放置在工作臺上，并通過夾具或定位裝置將其牢固固定，確保管材在切割過程中不會發生位移，保證切割精度。
激光發生與傳輸：數控系統控制光纖激光發生器產生高能量密度的激光束。激光束通過光纖傳輸至切割頭，在切割頭中，激光束被聚焦透鏡聚焦，形成極小的坡口切割光斑，從而在管材表面產生極高的能量密度。
切割頭運動控制：數控系統根據預先編制的切割程序，精確控制切割頭沿著管材的切割路徑進行移動。切割頭不僅可以沿著管材的軸向和徑向移動，還可以進行角度調整，以實現不同角度的坡口切割。
輔助氣體作用：在切割過程中，輔助氣體（如氧氣、氮?dú)獾龋┩ㄟ^切割頭噴出。輔助氣體一方面可以吹走管材在激光作用下熔化或汽化的材料，另一方面可以保護切割頭的鏡片，防止飛濺物對其造成損壞。同時，不同的輔助氣體在切割不同材質的管材時，還能起到促進切割過程、提高切割質量的作用。
坡口切割參數控制：操作人員根據管材的材質、壁厚、坡口角度等因素，在數控系統中設置合適的激光功率、切割速度、輔助氣體壓力等切割參數。數控系統根據這些參數精確控制激光發生器、切割頭和輔助氣體系統的工作，以達到理想的坡口切割效果。
應用區域：
建筑行業：用于建筑結構中管材的加工，如鋼結構建筑中的鋼管連接部位的坡口切割。可以切割出不同角度的坡口，方便管材之間的焊接，提高建筑結構的強度和穩定性。
機械制造行業：在機械零部件的加工中，臺式數控光纖激光坡口切管機可用于切割各種管材，如液壓缸體、機械臂管材等。能夠滿足不同機械對管材坡口精度和質量的要求，提高機械產品的性能和可靠性。
石油化工行業：適用于石油化工管道的加工，如油管、氣管等?？梢郧懈畛龇瞎に囈蟮钠驴?，保證管道連接的密封性和強度，防止泄漏等問題的發生。
汽車制造行業：用于汽車底盤、車架等部位的管材加工?？梢郧懈畛鼍_的坡口，便于管材的組裝和焊接，提高汽車的安全性和性能。
航空航天行業：在航空航天領域，對管材的加工精度和質量要求極高。臺式數控光纖激光坡口切管機可以切割出高精度的坡口，滿足航空航天零部件的加工需求，如飛機發動機管道、機身結構管材等的加工。
船舶制造行業：可用于船舶管道系統和結構件的管材加工，如船舶的冷卻管道、船體結構管材等。能夠切割出合適的坡口，提高船舶管道連接的可靠性和船體結構的強度。
I. Introduction to the working principle and application areas of the HT-TV-I full-automatic feeding servo follow-up CNC fiber laser pipe cutting machine (HT-TV-II full-automatic feeding servo follow-up CNC fiber laser bevel pipe cutting machine):
Working Principle:
Pipe Fixing and Positioning: Place the pipe to be cut on the workbench, and firmly fix it with clamps or positioning devices to ensure that the pipe will not move during the cutting process and guarantee the cutting accuracy.
Laser Generation and Transmission: The CNC system controls the fiber laser generator to generate a laser beam with high energy density. The laser beam is transmitted to the cutting head through the optical fiber. In the cutting head, the laser beam is focused by the focusing lens to form a very small bevel cutting spot, thus generating extremely high energy density on the surface of the pipe.
Cutting Head Movement Control: The CNC system precisely controls the cutting head to move along the cutting path of the pipe according to the pre-programmed cutting program. The cutting head can not only move axially and radially along the pipe but also adjust the angle to achieve bevel cutting at different angles.
Function of Auxiliary Gas: During the cutting process, auxiliary gases (such as oxygen, nitrogen, etc.) are ejected through the cutting head. On the one hand, the auxiliary gas can blow away the melted or vaporized material of the pipe under the action of the laser. On the other hand, it can protect the lens of the cutting head from being damaged by spatter. Meanwhile, different auxiliary gases can promote the cutting process and improve the cutting quality when cutting pipes of different materials.
Bevel Cutting Parameter Control: The operator sets appropriate cutting parameters such as laser power, cutting speed, and auxiliary gas pressure in the CNC system according to factors such as the material, wall thickness, and bevel angle of the pipe. The CNC system precisely controls the work of the laser generator, cutting head, and auxiliary gas system according to these parameters to achieve the ideal bevel cutting effect.
Application Areas:
Construction Industry: It is used for the processing of pipes in building structures, such as the bevel cutting of the connection parts of steel pipes in steel structure buildings. It can cut bevels at different angles, making it convenient for the welding of pipes and improving the strength and stability of the building structure.
Mechanical Manufacturing Industry: In the processing of mechanical parts, the desktop CNC fiber laser bevel pipe cutting machine can be used to cut various pipes, such as hydraulic cylinder bodies, pipes of robotic arms, etc. It can meet the requirements of different machines for the precision and quality of pipe bevels, improving the performance and reliability of mechanical products.
Petrochemical Industry: It is suitable for the processing of petrochemical pipes, such as oil pipes, gas pipes, etc. It can cut bevels that meet the technological requirements, ensure the sealing performance and strength of pipe connections, and prevent problems such as leakage.
Automobile Manufacturing Industry: It is used for the processing of pipes in parts such as the automobile chassis and frame. It can cut precise bevels, making it convenient for the assembly and welding of pipes and improving the safety and performance of automobiles.
Aerospace Industry: In the aerospace field, there are extremely high requirements for the processing precision and quality of pipes. The desktop CNC fiber laser bevel pipe cutting machine can cut high-precision bevels to meet the processing needs of aerospace components, such as the processing of pipes for aircraft engines and fuselage structure pipes.
Shipbuilding Industry: It can be used for the processing of pipes in the ship's pipeline system and structural parts, such as the cooling pipes of ships, hull structure pipes, etc. It can cut suitable bevels, improving the reliability of ship pipeline connections and the strength of the hull structure。
（HT-TV-I全自動上料伺服隨動數控光纖激光切管機(HT-TV-II全自動上料伺服隨動數控光纖坡口激光切管機工作視頻）
The working video of the HT-TV-I full-automatic feeding servo follow-up CNC fiber laser pipe cutting machine (HT-TV-II full-automatic feeding servo follow-up CNC fiber laser bevel pipe cutting machine) (for reference)。
二、HT-TV-I全自動上料伺服隨動數控光纖激光切管機(HT-TV-II全自動上料伺服隨動數控光纖坡口激光切管機)控制系統是一套高度集成化、智能化的工業自動化系統，主要由以下核心組件構成：
1.）柏楚 4000+ 數控系統
采用國內領先的柏楚電子控制系統，具備多軸聯動控制能力（支持 X/Y/Z/A/C 軸同步運動）
配備 15.6 英寸工業級觸控屏，分辨率達 1920×1080，支持手勢操作和快捷鍵功能
內置高速處理器（Intel i5 或更高配置），運算速度達 3200 脈沖 / 秒，確保復雜軌跡的精確控制
2.）運動控制卡
采用自主研發的高精度運動控制卡，支持 EtherCAT 總線通訊協議
具備電子齒輪箱功能，可實現切割頭與管材旋轉的同步跟隨
支持動態補償算法，自動修正機械誤差，定位精度達 ±0.03mm
）日本安川伺服電機
X/Y/Z 軸標配 1.5kW 高響應伺服電機，加速度達 1.5G
A/C 軸（旋轉軸）采用 2.2kW 高精度伺服電機，最小旋轉分辨率 0.001°
電機防護等級達 IP65，適應多粉塵的工業環境
）伺服驅動器
匹配安川 Sigma-7 系列驅動器，支持全閉環控制
內置振動抑制功能，有效減少高速運動時的機械抖動
支持再生能量回收，節能效率提升 20% 以上
）管材自動識別模塊
采用 3D 視覺傳感器（基恩士或歐姆龍品牌），可自動識別管材直徑（范圍 Φ10-Φ220mm）
支持管材長度自動測量（最大檢測長度 6000mm）
內置 AI 算法，可自動匹配切割工藝參數
）智能上料機器人
6 軸關節機器人（負載 20-50kg 可選），重復定位精度 ±0.05mm
配備自適應夾具，支持圓管、方管、矩形管的自動抓取
上料節拍≤8 秒 / 次，可實現 24 小時不間斷作業
）激光功率控制系統
）波刺黑金剛切割頭隨動系統
電容式高度跟蹤傳感器，響應速度≤1ms
動態跟隨范圍 ±10mm，適應管材表面不平整
具備碰撞保護功能，接觸力＞5N 時自動停機
)操作軟件
自主研發的 HT-Cut 3.0 專業切管軟件，支持中文 / 英文界面切換
內置 200+ 種標準管材切割工藝庫，覆蓋碳鋼、不銹鋼、鋁合金等材料
支持 DXF、DWG、IGES 等格式導入，自動生成切割路徑
0遠程監控模塊
支持 4G/5G/WiFi 網絡連接，可通過手機 APP 遠程監控設備狀態
內置故障診斷系統，可自動預警并提供解決方案
支持生產數據云端存儲和分析，實現數字化工廠管理
）多重安全聯鎖
全封閉防護艙門配備電磁感應開關，開門自動停機
激光防護等級達 Class 1，符合 CE 安全標準
急停按鈕分布于設備各操作區域，響應時間＜0.1s
）除塵與排煙系統
標配脈沖反吹式除塵器，過濾精度≤0.3μm
吸煙效率＞95%，確保工作環境符合職業健康標準
風速傳感器實時監測風道壓力，異常時自動報警
這套控制系統通過各組件的協同工作，實現了從管材上料、定位、切割到下料的全自動化流程，切割效率比傳統設備提升 30% 以上，適用于精密管材加工、工程機械制造、汽車零部件等高端制造領域。
II. The control system of the HT-TV-I full-automatic feeding servo follow-up CNC fiber laser pipe cutting machine (HT-TV-II full-automatic feeding servo follow-up CNC fiber laser bevel pipe cutting machine) is a highly integrated and intelligent industrial automation system, mainly composed of the following core components:
Core control unit
1.) Bodor 4000+ numerical control system
Adopt the leading Bodor electronic control system in China, with multi-axis linkage control capability (supporting synchronous movement of X/Y/Z/A/C axes)
Equipped with a 15.6-inch industrial-grade touch screen with a resolution of 1920×1080, supporting gesture operation and shortcut key functions
Built-in high-speed processor (Intel i5 or higher configuration), with an operation speed of 3200 pulses per second, ensuring precise control of complex trajectories
2.) Motion control card
Adopt the independently developed high-precision motion control card, supporting the EtherCAT bus communication protocol
Have the function of an electronic gearbox to achieve synchronous following of the cutting head and the rotation of the pipe
Support the dynamic compensation algorithm, automatically correct mechanical errors, and the positioning accuracy reaches ±0.03mm
Servo drive system
1.) Japanese Yaskawa servo motor
The X/Y/Z axes are standard equipped with 1.5kW high-response servo motors, with an acceleration of 1.5G
The A/C axes (rotary axes) adopt 2.2kW high-precision servo motors, with a minimum rotation resolution of 0.001°
The motor protection level reaches IP65, adapting to the industrial environment with a lot of dust
2.) Servo driver
Match the Yaskawa Sigma-7 series driver, supporting full closed-loop control
Built-in vibration suppression function, effectively reducing mechanical jitter during high-speed movement
Support regenerative energy recovery, and the energy-saving efficiency is increased by more than 20%
Automated feeding system
1.) Automatic pipe identification module
Adopt a 3D vision sensor (Keyence or Omron brand), which can automatically identify the pipe diameter (range Φ10-Φ220mm)
Support automatic measurement of the pipe length (maximum detection length of 6000mm)
Built-in AI algorithm, which can automatically match cutting process parameters
2.) Intelligent feeding robot
6-axis articulated robot (load of 20-50kg is optional), with a repeat positioning accuracy of ±0.05mm
Equipped with an adaptive fixture, supporting automatic grasping of round pipes, square pipes, and rectangular pipes
The feeding cycle is ≤ 8 seconds per time, and continuous operation for 24 hours can be achieved
Laser cutting control system
1.) Laser power control system
Deeply adapted to the Raycus laser, supporting stepless power adjustment from 0 to 100%
Built-in piercing expert system, which can automatically optimize piercing parameters according to the material thickness
Support the pulse cutting mode, with a frequency range of 1-5000Hz
2.) Wave-stimulation Black King Kong cutting head follow-up system
Capacitive height tracking sensor, with a response speed ≤ 1ms
Dynamic following range of ±10mm, adapting to the uneven surface of the pipe
Have a collision protection function, and automatically stop when the contact force > 5N
Human-machine interaction system
1.) Operation software
The independently developed HT-Cut 3.0 professional pipe cutting software supports the switching between Chinese and English interfaces
Built-in more than 200 standard pipe cutting process libraries, covering materials such as carbon steel, stainless steel, and aluminum alloy
Support the import of formats such as DXF, DWG, and IGES, and automatically generate cutting paths
2.) Remote monitoring module
Support 4G/5G/WiFi network connection, and the device status can be remotely monitored through the mobile phone APP
Built-in fault diagnosis system, which can automatically give early warnings and provide solutions
Support cloud storage and analysis of production data to achieve digital factory management
Safety protection system
1.) Multiple safety interlocks
The fully enclosed protective cabin door is equipped with an electromagnetic induction switch, and it will automatically stop when the door is opened
The laser protection level reaches Class 1, meeting the CE safety standard
Emergency stop buttons are distributed in each operation area of the equipment, with a response time < 0.1s
2.) Dust removal and smoke exhaust system
Standard pulse reverse blowing dust collector, with a filtration accuracy ≤ 0.3μm
The smoke suction efficiency > 95%, ensuring that the working environment meets the occupational health standard
The wind speed sensor monitors the air duct pressure in real time, and it will automatically alarm in case of an abnormality
Through the coordinated work of each component, this control system realizes the fully automated process from pipe feeding, positioning, cutting to unloading, and the cutting efficiency is increased by more than 30% compared with traditional equipment, which is suitable for high-end manufacturing fields such as precision pipe processing, construction machinery manufacturing, and automotive parts manufacturing
三、三卡盤結構 創新加工
三卡盤結構設計，加工過程采用三個卡盤夾持支撐，可對管材的彎曲、扭曲較大的管材調整夾持力進行矯正切割，可避免因管料后端抖動而影響前端切割精度，運行速度快、精度高、載重高。
Three Chuck Structure, Innovative Processing
With the design of the three chuck structure, during the processing, three chucks are used for clamping and supporting. For pipes with large bending and twisting, the clamping force can be adjusted for correction and cutting. It can prevent the cutting accuracy at the front end from being affected by the shaking of the rear end of the pipe material, featuring fast operation speed, high precision, and high load capacity.
四、負載大、范圍大
激光切管機的三卡盤結構，可避免因管料高速旋轉抖動而影響切割精度和效率。夾持范圍大，高承載力卡盤，可以完成多根圓管、方管、矩形鋼等材料多根夾持；最小夾持范圍可達15mm；最大夾持范圍可達500mm，最大承載可達2噸，更大填補重型管材切割需求，卡爪夾持力智能可調，夾持范圍可根據管材范圍快速更換。
IV. Large Load and Wide Range
The three-chuck structure of the laser pipe cutting machine can prevent the cutting accuracy and efficiency from being affected by the jitter of the pipe material during high-speed rotation. With a large clamping range and high-load chucks, it can clamp multiple materials such as round pipes, square pipes, and rectangular steel. The minimum clamping range can reach 15mm, and the maximum clamping range can reach 500mm. The maximum load capacity can reach 2 tons, which better meets the cutting needs of heavy-duty pipes. The clamping force of the chuck jaws can be intelligently adjusted, and the clamping range can be quickly replaced according to the range of the pipes五、標配進口IPG激光器或Raycus銳科優質激光器的激光器優點：
1.為用戶節省成本。
2.切割6mm以下的金屬板材只需要吹空氣(普通空氣0.6MPa-0.8MPa),而不需要氧氣。節省使用氧氣的費用。切割速度快于同類設備。
3.切割速度高于同類設備30%，切割速度達到每分鐘4米。
4、重管多根上料 重載下料。
5、側掛式導軌結構，防塵效果好；上料架型材上料，V型架接料，無需等待自動化程度高，質量最優。 對夾下料，可防止管材在運輸和切割過程中滾動儲料輸送架，可存儲多根管材，方便人員運輸，節省時間。
V. Advantages of the laser: The standard configuration includes imported IPG lasers or high-quality Raycus lasers：
Save costs for users.
When cutting metal sheets with a thickness of less than 6mm, only air (ordinary air at 0.6MPa - 0.8MPa) is required, and oxygen is not needed. This saves the cost of using oxygen. The cutting speed is faster than that of similar equipment.
The cutting speed is 30% higher than that of similar equipment, reaching 4 meters per minute.
Multiple heavy pipes can be loaded, and heavy-duty unloading is available.
The side-hanging guide rail structure has a good dust-proof effect; the material is loaded on the profile of the loading rack, and the V-shaped rack is used for receiving materials. There is no need to wait, and the degree of automation is high with the best quality. The opposite clamping unloading can prevent the pipes from rolling during transportation and cutting. The storage and conveying rack can store multiple pipes, which is convenient for personnel transportation and saves time
部分切割形狀圖（Partial cutting shape diagrams）
伺服隨動全自動上料數控光纖激光切管機特點說明：
1、本公司激光切割機采用先進國外進口IPG或Raycus(銳科)的激光器技術，光斑小，功率集中，割縫細、切割效率高，
2、采用柏楚4000+數控系統，采用優質先進的波刺黑金剛激光切割頭。
2.設備框架采用龍門雙絲杠、雙伺服電機同步驅動，運行平穩，切割精度高。這種方式只有數百萬元的大功率激光切割機采用。切割細線條、小圓等細小圖案，不變形，效果好。采用焦距跟隨設計，即使材料表面不平整仍可保證切割質量切縫平整、美觀，無需后序處理工序。
3.人性化設計的控制柜，方便用戶操作使用。
Characteristics Description of Servo-following Full-automatic Loading CNC Fiber Laser Pipe Cutting Machine:
The laser cutting machine of our company adopts the laser technology of imported IPG or Raycus (Ruike) from abroad. It has a small light spot, concentrated power, a narrow cutting seam, and high cutting efficiency.
It adopts the Bechuan 4000+ CNC system and high-quality and advanced Black King Kong laser cutting head of Bosi.
The equipment frame is driven synchronously by a gantry double lead screw and double servo motors, which runs stably and has high cutting precision. This method is only used in high-power laser cutting machines worth several million yuan. It can cut fine lines, small circles and other small patterns without deformation, and the effect is good. It adopts the focal length following design. Even if the surface of the material is uneven, it can still ensure the cutting quality. The cutting seam is flat and beautiful, and there is no need for subsequent processing procedures.
The control cabinet with a humanized design is convenient for users to operate
六、伺服隨動全自動上料數控光纖激光切管機技術參數：
型號 | HT-TR-12050 | HT-TR-9050 | HT-TR-12036 | HT-TR-9036 | HT-TR-L13050 |
加工范圍 | φ50-508mm | φ50-508mm | φ50-360mm | φ50-360mm | φ50-508mm |
□50-350mm | □50-350mm | □50-260mm | □50-260mm | □50-350mm |
定位精度 | ±0.03mm/m | ±0.03mm/m | ±0.03mm/m | ±0.03mm/m | ±0.03mm/m |
重復定位精度 | ±0.05mm | ±0.05mm | ±0.05mm | ±0.05mm | ±0.05mm |
最大空運行速度 | 40m/min | 40m/min | 60m/min | 60m/min | 40m/min |
最大空轉速度 | 50r/min | 50r/min | 80r/min | 80r/min | 50r/min |
單根管材最大質量 | 2000kg | 2000kg | 1200kg | 1200kg | 1500kg |
最大一次性下料尺寸 | 12000mm | 9000mm | 12000mm | 9000mm | 13000mm |
推薦功率段 | 1000W-80000W |
VI. Technical Parameters of the Servo-following Full-automatic Loading CNC Fiber Laser Pipe Cutting Machine：
| Processing Range | φ50-508mm
□50-350mm | φ50-508mm
□50-350mm | φ50-360mm
□50-260mm | φ50-360mm
□50-260mm | φ50-508mm
□50-350mm |
| Positioning Accuracy | ±0.03mm/m | ±0.03mm/m | ±0.03mm/m | ±0.03mm/m | ±0.03mm/m |
| Repeat Positioning Accuracy | ±0.05mm | ±0.05mm | ±0.05mm | ±0.05mm | ±0.05mm |
| Maximum Idle Running Speed | 40m/min | 40m/min | 60m/min | 60m/min | 40m/min |
| Maximum Idle Speed | 50r/min | 50r/min | 80r/min | 80r/min | 50r/min |
| Maximum Mass of a Single Pipe | 2000kg | 2000kg | 1200kg | 1200kg | 1500kg |
| Maximum One-time Unloading Size | 12000mm | 9000mm | 12000mm | 9000mm | 12000mm |
備注：本資料所列數據為參考數據，如與機床實際數據不符，應以機床實際數據為準，以上參數如有變動，恕不另行通知，本公司保留對此資料的最終解釋權！
Remarks: The data listed in this document are for reference. In case of any discrepancy with the actual data of the machine tool, the actual data of the machine tool shall prevail. The above parameters are subject to change without prior notice. Our company reserves the right to interpret this document!
