HTB(G)-DA69W系列電液伺服數控折彎機( Series Electro-hydraulic Servo CNC Press Brake)工作原理Working Principle

      HTB(G)-DA69W系列8 + 1軸加機械工作臺補償電液伺服數控折彎機的工作原理融合了多軸聯動控制、電液伺服驅動以及獨特的機械工作臺補償機制，具體如下：

1. 電液伺服驅動原理：該折彎機采用先進的電液伺服系統。數控系統會根據操作人員預先輸入的加工參數（如板材材質、厚度、折彎角度、折彎長度等），經過精確的計算和分析后，向電液伺服閥發出對應的電信號。電液伺服閥依據這些電信號來精確控制液壓油的流量和流向，進而驅動液壓缸，實現對滑塊運動的精準控制，包括滑塊的下降速度、停止位置以及施加的壓力等，以確保折彎操作的準確性和穩定性。

2. 8 + 1軸聯動控制：“8 + 1軸” 意味著該折彎機具備多個可獨立運動且又能協同工作的軸。其中8軸通常涵蓋了滑塊的垂直運動軸（控制上下行程以實現折彎動作）、后擋料的多個定位軸（用于精確確定板材的位置，保證每次折彎的尺寸精度）等。另外1軸可能是指特定的輔助軸或具有特殊功能的軸。這些軸在數控系統的協調和控制下，能夠按照預設的程序和軌跡進行聯動運動，使得折彎機可以處理各種復雜的折彎任務，滿足不同形狀和尺寸的板材加工需求。

3. 機械工作臺補償原理：在折彎過程中，由于工作臺在承受較大壓力時會產生一定的變形，這種變形會影響到折彎的精度。為了克服這一問題，該折彎機配備了機械工作臺補償裝置。當滑塊向下運動對板材施加壓力進行折彎時，工作臺的變形情況會被檢測裝置實時監測（可能通過傳感器等設備）。數控系統根據檢測到的變形數據，計算出需要補償?shù)牧?，并控制機械補償裝置（如通過絲桿、螺母機構等）對工作臺的相應部位進行微調，增加或減少工作臺的局部高度，從而補償因工作臺變形而導致的折彎誤差，確保折彎角度和尺寸的高精度，提高加工質量。

4. 模具配合與折彎過程：折彎機上安裝有特定形狀和尺寸的上、下模具。上模具固定在滑塊上，下模具安裝在工作臺上。當滑塊在電液伺服系統的驅動下向下運動時，板材被放置在上、下模具之間，隨著滑塊的繼續下壓，板材在模具的作用下發生塑性變形，逐漸達到所需的折彎角度和形狀。在這個過程中，各軸的精確運動和機械工作臺補償機制共同作用，保證了折彎的準確性和一致性 。

5. 數控系統的核心作用：數控系統是整個折彎機的大腦，它不僅負責接收和處理操作人員輸入的各種加工參數，還能對電液伺服系統、各軸的運動以及機械工作臺補償裝置等進行實時監控和精確控制。通過內置的算法和程序，數控系統能夠根據不同的加工任務，自動調整各部分的工作狀態，實現自動化、智能化的折彎加工過程，同時還具備故障診斷、數據記錄和存儲等功能，方便操作人員進行設備維護和生產管理。

     The working principle of the HTB(G)-DA69W series 8 + 1-axis electro-hydraulic servo CNC press brake with mechanical worktable compensation integrates multi-axis linkage control, electro-hydraulic servo drive, and a unique mechanical worktable compensation mechanism, as follows:

1. Principle of Electro-hydraulic Servo Drive: This press brake adopts an advanced electro-hydraulic servo system. The CNC system will send corresponding electrical signals to the electro-hydraulic servo valve after precise calculation and analysis based on the processing parameters pre-entered by the operator (such as the material, thickness, bending angle, and bending length of the sheet metal, etc.). The electro-hydraulic servo valve precisely controls the flow and direction of the hydraulic oil according to these electrical signals, and then drives the hydraulic cylinder to achieve precise control of the movement of the slider, including the descending speed, stop position, and the applied pressure of the slider, to ensure the accuracy and stability of the bending operation.

2. 8 + 1-axis Linkage Control: "8 + 1-axis" means that this press brake has multiple axes that can move independently and work in coordination. Among them, the 8 axes usually include the vertical movement axis of the slider (controlling the up-and-down stroke to achieve the bending action), multiple positioning axes of the backgauge (used to accurately determine the position of the sheet metal to ensure the dimensional accuracy of each bending), etc. The additional 1 axis may refer to a specific auxiliary axis or an axis with special functions. Under the coordination and control of the CNC system, these axes can perform linkage movements according to the preset program and trajectory, enabling the press brake to handle various complex bending tasks and meet the processing requirements of sheet metals of different shapes and sizes.

3. Principle of Mechanical Worktable Compensation: During the bending process, the worktable will deform to a certain extent due to the large pressure it bears, and this deformation will affect the bending accuracy. To overcome this problem, this press brake is equipped with a mechanical worktable compensation device. When the slider moves downward to apply pressure to the sheet metal for bending, the deformation of the worktable will be monitored in real time by the detection device (possibly through sensors and other equipment). The CNC system calculates the required compensation amount according to the detected deformation data and controls the mechanical compensation device (such as through a screw and nut mechanism, etc.) to make fine adjustments to the corresponding parts of the worktable, increasing or decreasing the local height of the worktable, thereby compensating for the bending error caused by the deformation of the worktable, ensuring the high accuracy of the bending angle and dimensions, and improving the processing quality.

4. Mold Matching and Bending Process: Specific-shaped and sized upper and lower molds are installed on the press brake. The upper mold is fixed on the slider, and the lower mold is installed on the worktable. When the slider moves downward driven by the electro-hydraulic servo system, the sheet metal is placed between the upper and lower molds. As the slider continues to press down, the sheet metal undergoes plastic deformation under the action of the molds and gradually reaches the required bending angle and shape. During this process, the precise movement of each axis and the mechanical worktable compensation mechanism work together to ensure the accuracy and consistency of the bending.

5. The Core Role of the CNC System: The CNC system is the brain of the entire press brake. It is not only responsible for receiving and processing various processing parameters input by the operator but also for real-time monitoring and precise control of the electro-hydraulic servo system, the movement of each axis, and the mechanical worktable compensation device, etc. Through the built-in algorithms and programs, the CNC system can automatically adjust the working status of each part according to different processing tasks to achieve an automated and intelligent bending processing process. At the same time, it also has functions such as fault diagnosis, data recording, and storage, which is convenient for the operator to carry out equipment maintenance and production management.

一、設備特點：

本機床采用荷蘭進口DELEM DA69W數控系統或瑞士CYBELEC系統，

具有人性化吊臂；基于實時的windows操作系統，三維彩色圖形折彎機數控系統

   采用荷蘭 DELEM公司 DA69W數控系統或瑞士CYBELEC折彎機數控系統為使用者提供友好操作界面，高效率編程方式，和引以自豪穩定性集成于一體，將大大提高數控折彎機的工作效率。

圖形編程技術秉承Delem或GYBELEC傳統的編程優勢，真實比例顯示工件、模具和機床。

數控系統包括2D圖形編程軟件，具有折彎工序自動計算、工件干涉檢測和自學習數據庫，數據庫運用將大大提高折彎精度。

全功能3D圖形編程軟件清晰展示真實機床模具配置以及折彎實現的可行性。

采用更高效率算法優化整個Y軸、X軸、R軸和補償V軸工作循環，使得Y軸、X軸、R軸和補償V軸循環的周期縮短，提高機床工作效率，同時對Y軸調整和控制更為方便。

二、設備性能介紹：（設備標配）

1、整機采用鋼板焊接結構，并經整體振動處理；

2、一次裝夾整體加工，保障機身的剛性和加工精度；

3、標準為數控8+1軸，Y1 、Y2、 X1、X2、R1、R2、Z1、Z2＋ V；

4、電液伺服系統配合瑞士進口光柵尺，折彎精度更高；

5、液壓撓度自動補給，消除滑塊彎形對工件質量的影響；

6、原裝進口集成液壓控制系統減少管路安裝，克服漏油；

7、后擋料采用臺灣HIWIN（上銀）直線導軌及滾珠絲杠驅動，速度更快精度更高；

8、上模選用快速夾緊，減輕工人勞動強度，提高生產效率；

9、可選配荷蘭DELEMDA69G系統或瑞士CYBELEC系統；

10、可根據用戶需要，后定位可控制八軸；

11、可選配液壓上模夾緊。

12、增加數控軸另議。

I. Equipment Features:

This machine tool is equipped with the imported Dutch DELEM DA69W CNC system or the Swiss CYBELEC system.

It has a user-friendly boom. Based on the real-time Windows operating system, it is a three-dimensional color graphic CNC system for press brakes.

The adoption of the Dutch DELEM DA69W CNC system or the Swiss CYBELEC press brake CNC system provides users with a friendly operation interface, a high-efficiency programming method, and integrates the proud stability, which will greatly improve the working efficiency of the CNC press brake.

The graphic programming technology inherits the traditional programming advantages of Delem or GYBELEC, and displays the workpiece, mold, and machine tool in true proportion.

The CNC system includes 2D graphic programming software, which has functions such as automatic calculation of bending processes, workpiece interference detection, and a self-learning database. The application of the database will greatly improve the bending accuracy.

The full-featured 3D graphic programming software clearly shows the configuration of the real machine tool mold and the feasibility of bending.

A more efficient algorithm is used to optimize the entire working cycle of the Y-axis, X-axis, R-axis, and compensation V-axis, shortening the cycle period of the Y-axis, X-axis, R-axis, and compensation V-axis, improving the working efficiency of the machine tool. At the same time, it is more convenient to adjust and control the Y-axis.

II. Introduction to Equipment Performance: (Standard Configuration of the Equipment)

1. The whole machine adopts a steel plate welding structure and has been subjected to overall vibration treatment.

2. It is processed integrally in one clamping, ensuring the rigidity of the machine body and the processing accuracy.

3. The standard is a CNC 8 + 1 axis, namely Y1, Y2, X1, X2, R1, R2, Z1, Z2 + V.

4. The electro-hydraulic servo system, combined with the imported Swiss grating ruler, enables higher bending accuracy.

5. Automatic hydraulic deflection compensation eliminates the influence of the slider's deformation on the quality of the workpiece.

6. The original imported integrated hydraulic control system reduces pipeline installation and overcomes oil leakage problems.

7. The backgauge is driven by Taiwan HIWIN linear guides and ball screws, featuring faster speed and higher accuracy.

8. The upper mold is selected with a quick clamping device, reducing the labor intensity of workers and improving production efficiency.

9. The Dutch DELEMDA69G system or the Swiss CYBELEC system can be optionally configured.

10. According to the needs of users, the rear positioning can control eight axes.

11. Hydraulic upper mold clamping can be optionally configured.

12. Adding CNC axes will be discussed separately.

三、數控折彎機技術參數表(Technical Parameter Table of CNC Press Brake):
